Centrifugal extractor is a highly efficient liquid-liquid extraction equipment, which is widely used in chemical, pharmaceutical, hydrometallurgical and other fields, to achieve the transfer and separation of solutes between two immiscible liquids.

The working process of centrifugal extractor is mainly divided into two parts, the mixing mass transfer process and the centrifugal separation process. The two liquids to be mixed are mixed under the rotation of the drum or blades of the centrifugal extractor. The mixed liquid enters the drum after mixing. Driven by the drum, it rotates at high speed to generate centrifugal force. Under the action of centrifugal force, the liquid with high density gathers outward, and the liquid with low density gathers inward. The two liquids will gradually separate and form an interface. The liquid with high density on the outside is discharged from the extractor through the heavy phase outlet, and the liquid with low density on the inside is discharged from the extractor through the light phase outlet, thus completing the separation process.

However, in the actual operation process, entrainment (entrainment of one phase of liquid in another phase of liquid) is a common problem, which not only affects the extraction efficiency, but also have an adverse effect on the purity of the product. Therefore, it is crucial to take effective measures to avoid entrainment. Among them, the heavy phase weir plate, as an important component of the centrifugal extractor, plays a key role.

How to avoid entrainment in centrifugal extractor

1.Optimize speed and mixing intensity
The speed and mixing intensity of centrifugal extractors are important factors affecting entrainment. By adjusting the speed reasonably, the centrifugal force and the surface tension of the liquid can be balanced to reduce the breakage and entrainment of the liquid. At the same time, optimize the mixing intensity to ensure that the two-phase liquid is fully in contact while avoiding the generation of too much tiny liquid, thereby reducing the risk of entrainment.

2.Design the reasonable interface control device
In the centrifugal extractor, the interface control device, such as baffles and partitions, can effectively control the flow path and speed of the two-phase liquid and reduce the mutual collision and entrainment of the liquid. These devices can guide the liquid to flow along the predetermined path, maintain the stability of the phase interface, and improve the extraction efficiency.

3.Accurately control the extraction temperature and pressure
The extraction temperature and pressure have a significant effect on the stability and entrainment of the liquid. By accurately controlling the temperature and pressure during the extraction process, the viscosity and surface tension of the liquid can be reduced, and the breakage and entrainment of the liquid can be reduced. At the same time, suitable temperature and pressure conditions can also help improve extraction efficiency and product quality.

The key role of the heavy phase weir plate

1.Blocking entrained liquid
The heavy phase weir plate is located at the heavy phase outlet of the centrifugal extractor. Its main function is to block and collect the light phase liquid entrained in the heavy phase liquid. When the heavy phase liquid flows through the weir plate, due to the effect of gravity, the light phase liquid will be deposited on the weir plate and gradually gather into a larger liquid, and finally slide back to the light phase area along the weir plate, thereby effectively reducing the entrainment phenomenon.

2.Stabilizing the phase interface
The heavy phase weir plate can also stabilize the phase interface. In the centrifugal extraction process, the stability of the phase interface is crucial to the extraction efficiency and product quality. The design of the heavy phase weir plate can guide the heavy phase liquid to flow out smoothly, while preventing the light phase liquid from excessively penetrating or disturbing the phase interface, and keeping the phase interface clear and stable.

3.Adjusting the flow distribution
By adjusting the parameters such as the height, width and shape of the heavy phase weir plate, the flow of the heavy phase liquid can be adjusted and controlled. Reasonable flow distribution helps to reduce the collision frequency and entrainment risk of the liquid, while improving the extraction efficiency and product quality. In addition, the heavy phase weir plate can be flexibly adjusted and optimized according to process requirements to meet the needs of different application scenarios.

The key to avoiding entrainment in centrifugal extractor is to optimize operating conditions, design reasonable phase interface control devices, and accurately control extraction temperature and pressure. As one of the important components of centrifugal extractor, the heavy phase weir plate plays a key role in blocking entrained liquid, stabilizing the phase interface, and regulating flow distribution. By giving full play to the role of the heavy phase weir plate and combining other effective measures, the occurrence of entrainment can be significantly reduced, and the extraction efficiency and product quality can be improved.
